High Quality 7S / 8S BMS Board with Temp Sensor for 100A-200A LiFePO4 Pack | 7S 8S BMS


Size: 7s li-ion
Style: 100A
Price:
Sale price$49.99

Description

Product Description--

Model: CF-SW24S200A-C 7S/ 8S



Product name:

7S Li-ion battery protection board for 24V-100A150A200A

 8S Lifepo4 battery protection board for 24V-100A150A200A



Specifications:

7S Li-ion battery protection board for 100A with  balance and temperature control 144g

7S Li-ion battery protection board for 150A with  balance and temperature control 208g

7S Li-ion battery protection board for 200A with  balance and temperature control 220g

8S Lifepo4 battery protection board for 100A with  balance and temperature control 144g

8S Lifepo4 battery protection board for 150A with  balance and temperature control 214g

8S Lifepo4 battery protection board for 200A with  balance and temperature control 218g



Size:

132*80*10MM (100A)

132*80*16MM (150A 200A)



Parameters--

Charging current: ≤50A/50A/60A

Discharge current: 100A/150A/200A

Internal resistance: ≤15mΩ



Short circuit protection--

Trigger condition: external short circuit

Detection delay: 300us

Release condition: disconnect the load



Temperature control protection——

Charge and discharge over-temperature protection: 55℃

Charge and discharge high temperature release temperature: 75℃

Release condition:During normal working temperature



Self-consumption——

Working power consumption: <35UA

Over-discharge power consumption(Sleeping State): <10UA

Operating temperature range: -30°~+80°C



 Li-ion BMS:

Charging voltage:

The number of Li-ion battery in series connection X 4.2V





Overcharge protection——

Detection voltage: 4.25±0.025V

Detection delay: 1000±500MS

Release voltage: 4.15±0.05V



Over-discharge voltage protection——

Detection voltage: 2.75±0.1V

Detection delay: 1000±500MS

Release voltage: 3.0±0.1V



Balanced voltage——

Detection voltage: 4.15±0.025V

Detection delay: 100±50MS

Balance current: 42±5MA



Over discharge current protection——

Detection voltage: 50±15MV

Detection delay: 1000±500MS

Current protection: 300±50A 450±50A 600±60A



LiFePO4 BMS:

Charging voltage:

The number of Lifepo4 battery in series connection X 3.65V





Overcharge protection——

Detection voltage: 3.65±0.025V

Detection delay: 1000±500MS

Release voltage: 3.55±0.05V



Over-discharge voltage protection——

Detection voltage: 2.35±0.1V

Detection delay: 1000±500MS

Release voltage: 2.7±0.1V



Balanced voltage——

Detection voltage: 3.5±0.025V

Detection delay: 100±50MS

Balance current: 36±5MA



Over discharge current protection——

Detection voltage: 50±15MV

Detection delay: 1000±500MS

Current protection: 300±50A 450±50A 600±50A









Product Features--

Overcharge protection

Over discharge protection

Overcurrent protection

Balanced protection

Static Protection

GPS port

Weak switch

Temperature control protection







Product Advantages--

  1. Open cooling system

Using heat sink anodic oxidation technology, the temperature can be radiated to the outside stably and safely.



  1. New MOS low internal resistance

Multiple optimized protection management schemes stably reduce the internal resistance of the circuit, increase the service life, and ensure safety and reliability.



  1. The function of disconnection protection!

Any string of battery packs, zero cell voltage, and any cable disconnection can protect the battery from no output.



  1. GPS port, balanced protection

Can GPS port, balanced protection; Can be connected to weak current switch, built-in temperature control.



  1. Smart chip, build an ideal life!

It is carefully made with high-quality components to achieve a series of functions such as high service life, strong endurance, and low charge and discharge temperature.



  1. The layout is clearly visible!

The inside to the outside of the protection board is intuitively visible, and each part can be clearly understood.

mosfet for 8s bms
7s bms with temp sensor
8s bms component
200a 8s bms wiring diagram
