Description
Warm Tips:
S1&S1X only applicable VESC/FSESC/Focbox, or other VESC-based ESCs. If you use other ESCs, it may fail to work.
The NELF S1X red board is the updated version of S1X black board, plug and play, more convenient.
Specifications:
| Rated voltage | 4.5V-5.5V |
| Minimum current value | 0.5A |
| Operating temperature | -40-85°C |
| Optimum humidity | 85%RH |
| Connection method | WIFI radio |
| Size | 38X22X12mm |
| Net weight | 6g |
| Language | English |
| Maximum lamp beads available | 2048 |
| Standby state | 3 modes |
| Moving state | 8 modes |
| Braking state | 8 modes |
| LED strip types available | APA102, WS2801, WS2811, WS2812, WS2813, WS2815, SK2812, HD107S, GS8208... |
| Color mode | support customization except for a few modes with mark * |
| Blinking slowly for 3 seconds | starting |
| Flashing once | mode switch has just been performed |
| Fast flashing | be reset to the factory state |
| Steady on | working |
| Inner packing size | 130*110*20mm |
| Inner packaging weight | 80g |
| Outer packing size | 160*120*75mm |
| Outer packaging weight | 200g |
| Recommended ESC | VESC/ FSESC/ Focbox |
Shipping Package:
5V S1X
1x PCB main control red board NELF S1X (PCB) (soldered wire)
1x PCB power board 9-90V to 5V step-down module (welded wire)
2x JST-2P line (male)
2x SM2.54-3P line
2x SM2.54-4P line
1x HY2.0-4P to 2.0-7P line
1x HY2.0-4P to 2.0 8P line
1x XT60 conversion head
12V S1X
1x PCB main control red board NELF S1X (PCB) (soldered wire)
1x PCB power board 9-90V to 12V step-down module (welded wire)
2x JST-2P line (male)
2x SM2.54-3P line
2x SM2.54-4P line
1x HY2.0-4P to 2.0-7P line
1x HY2.0-4P to 2.0 8P line
1x XT60 conversion head
5V S1X + 5V WS2812 1M*2
1x PCB main control red board NELF S1X (PCB) (soldered wire)
1x PCB power board 9-90V to 5V step-down module (welded wire)
2x JST-2P line (male)
2x SM2.54-3P line
2x SM2.54-4P line
1x HY2.0-4P to 2.0-7P line
1x HY2.0-4P to 2.0 8P line
1x XT60 conversion head
1x WS 2812 LED strip 2m 5V
Note: LED strips purchased in our store will be sticked with tape in the backside. If you need LED strip with different length, please leave note or contact us.
