Description
Parameter:
Product name: 12V 12A 3S Li-ion BMS Board Same Port without Balance
Size: 34*33*1.2mm
Application: Nominal Li-ion 3.7V battery
Current: 12A
Voltage: 12.6V
Overcharge protection-
Detection voltage: 4.25V±0.025V
Detection delay: 1000±500MS
Release voltage: 4.15±0.05V
Over-discharge voltage protection-
Detection voltage: 2.7±0.1V
Detection delay: 1000±500MS
Release voltage: 3.0±0.1V
Discharge over current protection-
Detection voltage: 100MV
Detection delay: 1000±500MS
Current protection: 30±5A
Short circuit protection-
Trigger condition: external short circuit
Detection delay: <300us
Release condition: disconnect the load
Self-consumption
Working power consumption: <35UA
Sleep over-discharge power consumption: <10UA
Operating temperature range: -30°~+80°C
Shipping list:
2pcs/5pcs/10pcs X 3S Li-ion battery BMS board same port without balance
